Grays Level Crossing

Latitude: 51.4763 / 51°28'34"N

Longitude: 0.3228 / 0°19'22"E

OS Eastings: 561407

OS Northings: 177816

OS Grid: TQ614778

Mapcode National: GBR YS.N1V

Mapcode Global: VHHNW.K503

Pluscode: 9F32F8GF+G4

What3Words: design.cubs.tone

Is the location marker in the wrong place? You can help fix that!

Name: Grays
Crossing Type: Public Manually Controlled Barriers (locally monitored by CCTV)
Location: Thurrock (B)
Postcode: RM176NN
Route: Anglia
ELR: TLL0
Distance: 19 miles 76 chains

Individual risk rating: D (High)
Collective risk rating: 2 (Very High)
Last assessment: October 2020
Next assessment due: January 2020
Types of trains: Passenger & Freight
Line speed: 60
Trains per day: 129
Usage:
- Infrequent vehicular use
- 7666 Pedestrians or Cyclists
Misuse history: 65 incidents in year prior to assessment date (Feb-2015), - 124 incidents since.
Near-miss history: 1 incident in year prior to assessment date (Feb-2015), - Nil incidents since.
Accident history: 2 incidents in year prior to assessment date (Feb-2015), - 5 incidents since.
Key risk factors:
- Crossing is Near a Station
- Large Numbers of Users
- Frequent Trains
Crossing protection arrangements:
- Train signalling protection
- CCTV monitoring by Signaller
- Road traffic light signals
- Full barrier equipment
- Audible alarm
- Signage

Notes

Individual Risk Rating is the risk to invidual users of the crossing. It is presented as a single letter, with A being the highest risk and M being the lowest.
Collective Risk Rating is the overall risk of any incident involving any person or vehicle on the crossing, including train staff and passengers as well as users of the crossing. It is presented as a number, with 1 being the highest risk and 13 being the lowest. This is the most important rating when prioritising safety measures at level crossings.
