Belmont Level Crossing

Latitude: 55.4451 / 55°26'42"N

Longitude: -4.6219 / 4°37'19"W

OS Eastings: 234253

OS Northings: 619929

OS Grid: NS342199

Mapcode National: GBR 3B.Z0C2

Mapcode Global: WH2PW.ZD7K

Pluscode: 9C7QC9WH+26

What3Words: quick.tiny.carbon

Is the location marker in the wrong place? You can help fix that!

We don't yet have any user-contributed photos of Belmont Level Crossing.

Name: Belmont
Crossing Type: Public Highway Manually Controlled Barriers (locally monitored by CCTV)
Location: South Ayrshire
Postcode: KA7 2PH
Route: Scotland
ELR: STR1
Distance: 41 miles 45 chains

Individual risk rating: J ()
Collective risk rating: 5 (High)
Last assessment: October 2018
Next assessment due: January 2022
Types of trains: Passenger & Freight
Line speed: 60
Trains per day: 40
Usage:
- 5913 Vehicles
- 270 Pedestrians or Cyclists
Misuse history: 2 incidents in year prior to assessment date (Oct-2015), - Nil incidents since.
Near-miss history: Nil incidents in year prior to assessment date (Oct-2015), - Nil incidents since.
Accident history: Nil incidents in year prior to assessment date (Oct-2015), - Nil incidents since.
Key risk factors:
- Large Numbers of Users
Crossing protection arrangements:
- Train signalling protection
- CCTV monitoring by Signaller
- Road traffic light signals
- Full barrier equipment
- Audible alarm
- Signage

Notes

Individual Risk Rating is the risk to invidual users of the crossing. It is presented as a single letter, with A being the highest risk and M being the lowest.
Collective Risk Rating is the overall risk of any incident involving any person or vehicle on the crossing, including train staff and passengers as well as users of the crossing. It is presented as a number, with 1 being the highest risk and 13 being the lowest. This is the most important rating when prioritising safety measures at level crossings.
